Trevitech dry-running protection, type Logicstop PLUS
Trevitech dry-running protection, type Logicstop PLUS
SKU:15531086
Regular price
Cg. 161.82
Regular price
Sale price
Cg. 161.82
Unit price
per
Delivery on request
Specifications
Complementary products v2
ProductListDrop
Type
Logicstop Plus
Voltage
230 V
Description
The Trevitech Logicstop PLUS dry-run protection device stops the pump in the event of a water shortage, thus preventing it from running dry. It also switches the pump off if the power consumption exceeds 10 A, thus also protecting the pump against overcurrent.
The dry-run/pump protection device is plugged into the wall socket, and the pump is then connected to it. As soon as the water stops flowing, the dry-run protection device will switch the pump off. This prevents damage to the pump caused by running dry.
In the event of a temporary power failure, the dry-run protection will automatically switch the pump back on as soon as the power is restored.
The Logicstop PLUS is suitable for pumps with a power consumption of 6 to 10 ampere.
The dry-run/pump protection device is plugged into the wall socket, and the pump is then connected to it. As soon as the water stops flowing, the dry-run protection device will switch the pump off. This prevents damage to the pump caused by running dry.
In the event of a temporary power failure, the dry-run protection will automatically switch the pump back on as soon as the power is restored.
The Logicstop PLUS is suitable for pumps with a power consumption of 6 to 10 ampere.
Setting
This dry-run protection device adjusts itself to the values it measures when the pump is working properly:- Plug the pump into the socket and make sure it is working properly.
- Then plug the dry-run protection device into the wall socket and plug the pump in.
- After a few seconds, the protection device will save the measured current as a default value.
Display
The dry-run protection device has a clear display showing the following:- Power on.
- Pomp on.
- Fault (dry running or overcurrent).
- Restart.
Do you want to buy a dry-run protection device or need more information?
The desired dry-run protection device can be ordered easily and quickly via our website or purchased at one of our branches. Are you not yet sure which dry-run protection device would be best for your situation? Contact one of our pump specialists for advice without obligation.
